Eaton 9E 1000 VA 800 W Input C14 Output (4) C13 Tower Online UPS

Eaton 9E UPS, 1000 VA, 800 W, Input: C14, Output: (4) C13, Tower General specifications Product Name Eaton 9E UPS Catalog Number 9E1000I UPC 786689166564 Product Length/Depth 356 mm Product Height 228 mm Product Width 144 mm Product Weight 22.1 kg Compliances CE Marked TUV Certifications IEC/EN 62040-1 IEC/EN 62040-2 CE EAC Battery Battery type Sealed, lead-acid Runtime graph View runtime graph Battery replacement Replacable batteries Battery quantity 2 Battery management Automatic battery test Deep discharge protection Battery rating 12 V / 9 Ah Extended battery capability Yes Electrical output Receptacle (4) C13 Voltage 230V Wattage 800 W Output power factor 0.8 Output voltage range 220/230/240 V +/- 2% Output waveform Sine wave Output nominal voltage 230V default (220/230/240V) Voltage distortion output (linear load) - max 3 Feed type 1 Topology Online/Double-conversion VA rating 1000 VA Electrical input Input connection C14 Input nominal voltage 230V default (220/230/240V) Nominal frequency 50/60 Hz Input power factor >.99 Input voltage range 176-300 V (100 V-300 V with derating) Input frequency range 40-70 Hz Communications Includes network card No Communication USB port (HID compliant) Serial port (RS232) Communication slot Ethernet interface No User interface LCD Display Potential free switch contact No Expansion slots One slot for optional communication card Software compatibility Eaton Intelligent Power Manager, Eaton Intelligent Power Protector Type of interface Other Environmental Altitude 3000 m Noise level 37 dB at 1 meter Temperature range 0° to 40°C (32° to 104°F) Relative humidity 0-95% non-condensing Additional specifications Construction type Free standing model Package contents UPS USB cable Serial cable Quickstart guide Safety instructions Phase (output) 1 Internal bypass Yes Auto shutdown function Yes Color Black Efficiency 91 Rack mounting kit No Phase (input) 1 Hot swap power No
